Highly Accurate 202g Digital Thermometer for -80 to 300 deg C Temperature Measurement

Name: Highly Accurate 202g Digital Thermometer for 80 to 300 deg C Temperature Measurement
Brand: Dearto
Price: 500.00 USD

Buy cheap Highly Accurate 202g Digital Thermometer for -80 to 300 deg C Temperature Measurement product

Warranty : 1 Year

Customized support : OEM, ODM, OBM

Place of Origin : Shandong, China

Brand Name : Dearto

Model Number : DTSW Series

Stability : ±0.05℃/1 year

Display resolution : 0.001℃

Dimension of main body : 106mm*48mm*37mm

Weight : 202g

Sensor texture : 316stainless steel

Display : LCD Screen

Power supply : Rechargeable lithium battery

Certification : ISO9001

Packaging Details : Customizable Packing

Supply Ability : 1000 Piece/Pieces per Month

Price : $500.00 - $1,500.00/sets

MOQ : 1

Contact Now

Products Description

The best alternative to mercury thermometers

DTSW rod type standard (precision) digital thermometer, is the latest in the field of industrial temperature calibration,precision measurement, its accuracy and repeatability can be achieved better than 0.05 ℃ / year, lithium batteries don't need to replace the battery life long, easy to carry and intuitive readings, strong and durable. It can not only be used as a temperature standard in the laboratory, but also can provide reliable, accurate and high-precision temperature measurement in the industrial field.

Product Features

Highly Accurate 202g Digital Thermometer for -80 to 300 deg C Temperature Measurement

- Accurate and reliable: excellent accuracy indexes, annual change is better than that of 0.05 ℃, the electric temperature less than 1 PPM / ℃
- Wireless communication: real-time data can be transmitted to the computer screen through wireless communication
- Curve display: computer software can display 32 thermometer real-time curves simultaneously
- Data recording: it can store the temperature measurement results of 16,000 bands
- Intelligent indication: trend indicator shows the trend of temperature change
- Zero mark: any zero mark, volatility, deviation value intuitive display
- Intelligent processing: the maximum, minimum and average values are directly calculated and displayed
- Unit conversion: K, ℃, ℉ can be arbitrary switching
- Display of resistance value: the resistance value of the sensor is displayed synchronously with the temperature value
- Regular shutdown: you can set the shutdown time from 1 minute to 48 hours
- Ultra low power consumption: no battery replacement for life
- Sampling adjustable: sampling cycle from 1S to 2H can be customized to facilitate timed sampling
- Clean and corrosion resistant: the probe of food grade 316 stainless steel is corrosion resistant and easy to clean
- Easy to charge: the charging port is compatible with the mobile phone, and any standard USB port can be easily charged

Wireless data transmission:

The Stick standardDigital Thermometer have wireless data transmission function, which can transmit the collected real-time data and historical data to the computer software remotely through 2.4G wireless communication, and analyze, process, save and export the data through the computer software. Intuitive and convenient use, the Stick Digital Thermometer won the favor of customers.

Wireless transmission application scenarios:
Wireless remote real-time reading temperature: remotely from the device under test, remotely read temperature values
Wireless data export:

Can read thermometer historical measurement data without connecting lines

Software function

The digital thermometer management software can display the value collected by the digital thermometer to the computer in real time through wireless transmission. It can also read the internal history data of the thermometer to the computer, or read and display the historical data saved by the computer. The temperature curve of each thermometer is displayed in real time on the right side. The top can read the current mainstream desktop digital meter values for displaying standard temperature values.

Software features

- Multi-channel display: as many as 32 thermometers are collected in real time, and the maximum quantity can be expanded according to the user's demand
- Intelligent curve: The thermometer curve is displayed in real time on the right side, and the channel, color and thickness can be freely configured.
- Digital table support: support mainstream 5 1/2, 6 1/2, 7 1/2, 8 1/2 desktop digital table
- Standard support: support standard platinum resistance data calculation, just enter the value of the certificate can be used
- One-click readout: the historical temperature data saved by the thermometer can be read into the software
- Report export: the data collected from the thermometer can be exported to the EXCEL table for analysis
- Data import: it can import the historical data saved in the computer into the software to display the curve
- Target value marking: the target value can be set in the curve to view the heating and cooling time and curve of the constant temperature source
- Thermometer calibration: support up to 64 point difference calibration of the thermometer
- Battery display: The remaining battery value of each thermometer is displayed in real time, and the power of each thermometer is clear at a glance.

Product Paramenters

Product Name	Stick standard(precision)digital thermometer							Digital thermometer
Model	DTSW-II	DTSW-1G-A	DTSW-1G-B	DTSW-2G	DTSW-kLG	DTSW-LcG
Temperature range	-5~60℃	-80~160℃	-80~300℃	-80~300℃	-80~400℃	-20~120℃
Accuracy	≤0.01℃	0.04℃+0.005%FS	0.05℃+0.01%FS	0.1℃/0.2℃(Industrial)	0.2℃(Industrial)	≤0.05℃
Calibration cycle	1 Year
Host temperature coefficient	<1ppm/℃
Length of sensor	300mm(11.81 in), 500mm(19.68 in)							1~1.5m
Sensor diameter	6mm							"1076-2020 calibration rule"
Sensor material	316 stainless steel (medical, food grade)							Flexible wire
Sensor specification	Thin film platinum resistance			Wire wound platinum resistance
Display resolution	0.001℃ (the user can be configured to 0.1 ℃, 0.01 ℃)
Sampling frequency	0.5s, 1S and 2S can be configured
Thermal response time constant	30S					Charging voltage	DC5V
Data storage	16,000 sets of data (with time stamp)					Host size	106(L)x48(W)x37(H)mm
Communications	USB and wireless communication					Total weight	202g
Wireless communication distance	No occlusion up to 160m					Preheating time	Preheat for 1 minute before use
The battery type	Lithium battery					Protection class	IP50
Lithium battery life	No less than 2000 cycles of charge and discharge					Lithium battery charging time	2 hours
Working temperature of communication module	−20℃ - 60℃(-4℉-140℉)					Host working environment	−10℃ - 50℃(14℉-122℉)
Storage condition	−20℃-60℃(−4℉-140℉) 5%RH-80%RH(Without condensation)

Highly Accurate 202g Digital Thermometer for -80 to 300 deg C Temperature Measurement Images
